The Sigma-7 family from Yaskawa is aimed at bringing greater responsiveness, efficiency and reliability to large-scale industrial applications, featuring a family of rotary, direct drive and linear servo products. The S7G Gear Motors ranges from 50W – 15kW suitable for a range of in-demand motion networks.
In a move to increase speed and flexibility of end-of-arm tooling creation, PCC has invested in SOLIDWORKS design software and 3D printing hardware from Markforged. PCC selected GSC as their reseller/training partner for both tools not only for GSC’s high level of technical and training resources, but proximity played a role as GSC is just two blocks from PCC’s Germantown WI headquarters. Vice President Business Development Dan Carney, who is heading up the robotics solutions team at PCC, said “GSC was an easy choice given their reputation in the SOLIDWORKS community and their location was just a nice bonus”.
Learn more about PCC’s Collaborative Robot Machine Tending Solution
This gripper was created on PCC’s new Markforged Onyx One printer. PCC has the ability to design and print a wide variety of mechanical items to customize end-of-arm work holding as well as custom brackets for after-market door control. Contact us to learn more.
The hallmark of Yaskawa’s machine controller MPiec series, the MP3200 offers support for a variety of applications with capabilities ranging from 1 – 62 axes. With a clock speed of 1GHz and extended network capabilities compatible with OPC, Ethernet/IP, Modbus TCP, etc. the controller can handle the most demanding plant applications with reliability, efficiency and safety.
Laser scanners serve as a safeguarding mechanism in places where normal devices such as emergency plungers and pushbuttons aren’t viable. The technology used within laser scanners is called “time-of-flight”, which involves the scanner calculating the position of the object based on the time taken by the laser to travel back.
R-rated fuses act as back-up devices for protection against short circuits, which otherwise may damage voltage starter and motors. The guidelines for applying these fuses are fundamentally different from low voltage protection devices.
Modular Automation Set 1 for SAFE low-voltage motor control
Stopping in an emergency
Application Areas: This Modular Automation Set is suited for a wide range of applications in plant and machinery construction:l Conveyor Systems
Production Lines
Process Control
Hoisting Equipment
Pump/Compressor Control
View the Modular Automation Set
IIoT is no longer a concept limited to research papers, conferences and keynote speeches; it is here. The deployment of the Internet of Things within manufacturing and other sectors has been building over the years and has now adopted an exponential pattern. Big Data Paradigm, M2M communication, and advanced sensory technologies are just some of the hotspots of Industrial IoT. The benefits are visible and include operational efficiency, greater on-site safety, and higher productivity.
Carlo Gavazzi is excited to announce the launch of our new IBS, ICS and ICB Series Inductive Proximity Sensors with integrated IO-Link communications.
The IBS 04 & ICS 05 and 08 Series represent the ideal solution for industrial automation applications where space is limited, but long switching distance is needed. They are available in robust Ø4mm, M5 or M8 stainless steel housings, with an M8 plug or two meter PVC cable.
The new generation of the ICB 12, 18 and 30 Series are a comprehensive family of high performance inductive proximity sensors for contactless and wear-free detection of metallic objects. They are available in durable nickel-plated brass housings, offered in three diameters: M12, M18 and M30, with an extended sensing distance range between 4 and 22 mm. They are also available with an M12 plug or two meter PVC cable.
Once connected to an IO-Link master, these sensors can be easily and completely configured; enabling additional advanced functionalities such as the detection counter (RPM) and the speed controller. Each sensor then becomes fully programmable and provides the means for hundreds of configurations in one single device.
View the IO-Link Brochure >>
IBS 04 and ICS 05/08 Proximity Sensors with IO-Link features:
IP67 Stainless steel Ø4, M5 or M8 barrel housing
Sensing distance from 0.8 mm up to 4 mm
Flush and non-flush versions
Output DC 100 mA
NPN or PNP, NO or NC or programmable
2 m PVC cable or M8-plug
Up to 2kHz (M8) or 6kHz (Ø4 or M5) operating freq.
Adjustable sensing distance and hysteresis and configurable output
Clearly visible LED with diagnostic functions
Operating temp.: -25°C to +80°C (-13°F to +176°F)
IO-Link communication V 1.1
ICB 12/18/30 Proximity Sensors with IO-Link features:
IP67 Nickel-plated brass M12, M18 or M30 cylindrical threaded barrel housings
Sensing distance from 4 mm to 22 mm
Flush and non-flush versions
Output DC 200 mA
2 m PVC cable or M12-plug
Up to 2 kHz operating frequency
Adjustable sensing distance and hysteresis and configurable output
Operating temp.: -25°C to +70°C (-13°F to +158°F), and -40°C to +70°C (-40° to +158°F) for M12-plug version
IO-Link communication V 1.1
The IO-Link inductive sensors were designed for use in specific markets such as Plastic & Rubber, Material Handling, Packaging and Machine Tool, providing the ideal solutions for demanding application needs.
Please join Siemens for a 1 day interactive seminar on the innovations for an automation solution geared for Industry 4.0, Digitalization, IIOT, and Smart Manufacturing. These innovations are key to ensuring a shorter time to market, increased flexibility, reduced engineering, and more transparency and data analytics.
Agenda:
8:30 AM – 10:00 AM Technology Showcase: Experience firsthand the products that enable the digital thread and data connectivity behind digitalization
10:00 AM – 12:30 PM Interactive Seminar: Innovations for Smart Manufacturing Part 1
12:30 PM – 1:30 PM Lunch and networking: Where are you in your digital journey?
1:30 PM – 3:00 PM Interactive Seminar: Innovations for Smart Manufacturing Part 2
Location:
Harley-Davidson Museum 500 West Canal Street Milwaukee, Wisconsin 53203
Date:
Thursday, March 7, 2019
Register Now!
Discover the advantages of partnering with Siemens…
The Siemens Digital Enterprise solution: starts with Totally Integrated Automation (TIA) and TIA Portal–a single engineering framework that seamlessly integrates multiple controllers, distributed I/O, HMI, drives, motion control and data acquisition and reporting
Our comprehensive set of support, training, and tools –including no-charge code-conversion services and instructions for converting your current project to the TIA Portal while retaining your naming conventions, allowing familiarity from the start
Our comprehensive, competitively priced automation portfolio that easily integrates with your existing system
Your benefits when embracing modernization boost ROI, increase productivity and enable transparency
Extend & improve safety, and security reduce engineering time by up to 30%
Positioned for the future
What automation solutions are positioned for IIOT?
To compete in the global market place, you must find new and innovative ways to reduce time-to-market, enhance flexibility and increase quality, efficiency and security.
Learn how to modernize your operation, while meeting your time and budget needs, to help position you for the future.
Cord grips are used to pass a cord or cable into an enclosure, through a bulkhead or into a control device like a switch. They seal an electrical connection from dirt, oil, moisture, dust and other contaminants—and can be used in dry or wet applications. Cord grips are used in industrial and commercial settings to control arc of bend or prevent cables from being pulled out of a system.
Learn more about Remke
